Batch-Generating WeChat Read's World Book Day Medals with Puppeteer

Background

As everyone knows, April 23 is World Book Day, and WeChat Read ran another campaign this year: generating a unique medal for every user.

How unique? Each medal carries two numbers. The one in the top-left is how many years the user has been on WeChat Read, and the one in the bottom-right is how many books they’ve read over those years.

For example, I’ve been on it for 8 years and read 230 books, so my medal looks like this 👇 (embarrassing, I really haven’t read much

My medal

The WeChat Read app has been around for 10 years in total, so the top-left number ranges from 1 to 10.

Of course, a person can read a lot of books, so we set a cap: anyone who has read more than 1000 books gets 999+.

So the most prestigious medal looks like this:

10-year 999+ medal

The medals are needed in 2 sizes, so the possible combinations are:

10 years * 1000 books * 2 sizes = 20000 medals

At that scale, if a designer drew them by hand, they’d still be at it by next year’s April 23.

So I threw together a tool to mass-produce them and free up the humans.

The main tools:

  • Node.js: the runtime
  • Puppeteer: page rendering and screenshots
  • EJS: templating
  • Sharp: image processing and optimization
  • Yargs: building the command-line interface

1. Expressing the Design Structure the Right Way

2. Template Rendering

With the EJS template engine, we can turn the medal design into a template:

<div class="diagram">
    <div class="circle">
        <div class="rectangle">
            <div class="number-image-container">
                <!-- Numbers rendered dynamically -->
            </div>
        </div>
    </div>
</div>

3. Taking Screenshots with Puppeteer

Puppeteer is a Node.js library that provides a high-level API for controlling Chrome/Chromium over the DevTools Protocol. It plays a key role in this project:

  1. Launch a headless browser instance
const browser = await puppeteer.launch({
    headless: true,
    args: ['--no-sandbox', '--disable-setuid-sandbox']
});
  1. Set up the canvas
const page = await browser.newPage();
await page.setViewport({
    width: w,
    height: h,
    deviceScaleFactor: scale
});
  1. Load the HTML
await page.setContent(html, {
    waitUntil: 'networkidle0',
    timeout: waitTime
});
  1. Take the screenshot
const screenshotBuffer = await page.screenshot({
    type: 'png',
    omitBackground: true,
    encoding: 'binary',
    fromSurface: true
});

4. Generating Medals Faster

To speed up generation, we built parallelism in at several levels:

  1. Worker pool
const workers = Array.from({ length: parallelCount }, async () => {
    const browser = await puppeteer.launch({
        headless: true,
        args: ['--no-sandbox', '--disable-setuid-sandbox']
    });
    const page = await browser.newPage();
    await page.setViewport({ width: w, height: h, deviceScaleFactor });
    return { browser, page, busy: false };
});
  1. Task dispatch
const processTask = async (worker, number) => {
    worker.busy = true;
    try {
        const result = await createMedal(
            worker.page,
            year,
            number,
            worker.index,
            quality,
            compressionLevel,
            waitTime
        );
        return result;
    } finally {
        worker.busy = false;
    }
};
  1. Dynamic load balancing
const getIdleWorker = () => workers.find(w => !w.busy);
const allWorkersIdle = () => workers.every(w => !w.busy);
  1. Progress tracking
const updateProgress = (success = true) => {
    if (success) {
        completed++;
    } else {
        failed++;
    }
    if ((completed + failed) % 10 === 0 || (completed + failed) === total) {
        console.log(`Progress: ${completed}/${total} (${Math.floor(completed/total*100)}%), failed: ${failed}`);
    }
};

5. Performance Optimizations

  1. Resource management

    • Reuse browser instances
    • Adjust parallelism dynamically
    • Free memory promptly

  2. Rendering optimizations

    • Use the networkidle0 wait strategy
    • Tune the page load timeout
    • Keep memory usage in check

  3. Concurrency control

    • Avoid resource contention
    • Dispatch tasks dynamically
    • Retry on errors

We chose networkidle0 for this project because it:

  1. Makes sure every image asset is fully loaded
  2. Avoids capturing half-loaded content in screenshots
  3. Guarantees the quality of the generated medal images

6. Image Compression

The medals were generated, but each one turned out to be 200-400 KB.

A medal weighing a few hundred KB is still too big to show in an H5 page, so we needed to shrink it.

Sharp is a Node.js image processing library, so we put it to work.

  1. Basic configuration
const sharp = require('sharp');

// Default options
const defaultOptions = {
    quality: 80,        // Image quality (0-100)
    compressionLevel: 9 // Compression level (0-9)
};
  1. Image processing pipeline
// Process and save the image
await sharp(screenshotBuffer)
    .png({
        quality: quality,           // Controls image quality
        compressionLevel: compressionLevel, // Controls compression level
        palette: false,             // We don't want to reduce colors, so skip palette optimization
        effort: 10                 // Compression effort (1-10)
    })
    .toFile(outputPath);
  1. Compression strategy in detail

  • Quality (quality)

    • Range: 0-100
    • Higher values mean better quality and larger files
    • Lower values mean worse quality and smaller files
    • Recommended: 80-90, to balance quality and size

  • Compression level (compressionLevel)

    • Range: 0-9
    • 0: fastest, but lowest compression ratio
    • 9: slowest, but highest compression ratio
    • Recommended: 6-9, depending on your needs

  • Batch processing

// Process multiple images in parallel
const processImage = async (buffer, options) => {
    return sharp(buffer)
        .png(options)
        .toBuffer();
};

const results = await Promise.all(
    images.map(img => processImage(img, options))
);
  • Error handling
try {
    await sharp(buffer)
        .png(options)
        .toFile(outputPath);
} catch (error) {
    console.error('Image processing failed:', error);
    // Fall back or retry
}

By tuning these parameters, we got:

  • 40-60% smaller files
  • Images that stay sharp
  • 30-50% faster processing

7. Usage Examples

# Generate a single medal
node index.js --year 2023 --number 42

# Generate all medals for a given year
node index.js --year 2023 --all

# Generate in parallel mode
node index.js --year 2023 --all --parallel 4

8. Key Technical Takeaways

  1. Template-driven design

    • Dynamic medal rendering with the EJS template engine
    • Support for custom background images and number styles
    • Flexible handling of numbers with different digit counts

  2. Automated generation

    • Batch-generate every medal for a given year
    • Parallel processing for better throughput
    • Automatic image compression and optimization

  3. Command-line tool

    • A friendly command-line interface
    • Many configurable options
    • Fine-grained control over the generation process

9. Closing Thoughts

This project shows how modern web technology can be applied to image generation. With a sensible architecture and some performance tuning, we built an efficient, reliable medal generator. It saved a lot of work, and it’s a reusable reference for similar needs.
